Kakute F7 Mini V3 Flight Controller

The Kakute F7 Mini Flight controller is the little brother of the Kakute F7.

It weighs only 4 grams and facilitates the construction of your drone and is compatible with several receivers like the SBUS, Spektrum, Crossfire and many others

Product content:

• x1 KAKUTE F7 Mini V3 Flight Controller
• x1 set of anti vibration grommets
• x1 set of JST cables

Technical Specifications:

• MCU: 32-bit processor STM32F722RET6, 216 MHz, 256 KB RAM, 512 KB Flash memory
• Model NO.: MPU6000 (SPI)
• Barometer: BMP280
• USB VCP driver (all UART can be used simultaneously; USB does not take UART)
• 5 Hardware UARTS (UART1,2,3,4,6)
• Supports serial receivers (SBUS, iBus, Spektrum, Crossfire) only. PPM and PWM receivers are not supported.
• Onbord 16 MB for Blackbox logging
• 5V power supply output: 1.0A max
• 3.3V Power supply output: 0.2A max
• Dimensions: 30x30mm
• Mounting holes: standard 20mm square in the center of the holes
• Weight: 4g
