Hitec D485HW Digital HV Servo

The HITEC D-Series HS D-485HW high-speed servos offer the highest resolution on the market today. The best response and programming possibilities are achieved thanks to the 32-bit MCU and the 12-bit ADC technology.

The 'D' series includes HITEC servos operating both in conventional voltage (4.8/6V) and HV (7.4V). So you can power it as you wish.

The HS-485HW Digital servo is fully programmable and offers good durability thanks to its robust steel gears and two ball bearings on the output shaft, which is particularly suitable when low backlash and high positioning accuracy are important.

The long service life and the uniquely designed transmission make it one of the most reliable and efficient servos on the market.

Technical characteristics:

• Width: 20 mm
• Height: 37 mm
• Length: 40 mm
• Weight: 45 gr
• Servo type: standard
• Special Features: wide-voltage digital
• sprockets: carbonit
• Operating voltage in V: 4.8-7.4 V
• Operating time s/60° at 4.8 volts: 0.20
• Operating time s/60° at 6.0 volts: 0.17
• Operating time s/60° at 7.4 volts: 0.15
• Torque in kgcm at 4.8 volts: 5.2
• Torque in kgcm at 6.0 volts: 6.4
• Torque in kgcm at 7.4 volts: 7.5
• Toothing: 25T
• Ball bearing: yes
• Waterproof: no
