VTX_EACHINE_TX805_(SMA)

Technical characteristics :


- Frequency:5.8 G

- Channels:40HP

- Input voltage: 7 V ~ 24 V

- 5 V camera power: 120mA (MAX) ---- 25 mW to 800 mW, 12 V

- Additional features: Smart audio

- Supply voltage: 5 V output to Camera

- Power output: 25 mW/200 mW/600 mW/800 mW switchable

- Antenna connector: MMCX

- Cable connector: pins for Welding

- Pitmode

- Support audio smart

- 40 channels with MIC

- Memory of power failure

- Switchable power supply 25/200/600 / 800mw

- OSD Configuration compatible via Betaflight FC

- Configuration of the power and frequency of a button

- Wide input voltage 7-24V with 5V for camera, value of current typical 12V:

25mw-120mA 200mw-200mA, 600mw-300mA 800mw-350mA

- Antenna connection solid MMCX and dipole antenna brass MMCX

- Dimensions: 36mm * 22mm * 5mm, 30.5 stackable hole

- Weight: 8g (excluding antenna)
